Txheej txheem cej luam ntawm Rail Hlau
Rail track yog ib qho tseem ceeb ntawm cov ciav hlau, thiab nws txoj haujlwm yog los coj cov tsheb ciav hlau nce mus rau pem hauv ntej los ntawm lub log loj heev tau thawb los ntawm lub log. Hlau Rail yuav tsum muab du, ruaj khov thiab txuas ntxiv rolling nto rau lub log tsheb ciav hlau dhau. Nyob rau hauv cov tsheb ciav hlau los yog tsis siv neeg thaiv ntu, kev tsheb ciav hlau kuj tseem siv tau raws li track Circuit Court.
Niaj hnub nails txhua tus siv cov hlau siv kub, thiab qhov tsis txaus me hauv cov hlau yuav ua rau muaj kev nyab xeeb ntawm kev tsheb ciav hlau thiab tsheb ciav hlau dhau. Yog li kev ntsia yuav tsum xeem qhov ntsuas nruj thiab ua tiav cov qauv zoo. Tus ntsia hlau hlau yuav tsum muaj peev xwm ntawm kev ntxhov siab ntau thiab tiv taus kev taug qab. Tus rail rail yuav tsum pub dawb los ntawm sab hauv cov kab nrib pleb thiab tiv taus kev qaug zog thiab hnav tsis kam.
Suav Txheem Teeb Rail
| Txheem: GB11264-89 | ||||||
| Qhov loj | Dimension (mm) | Qho hnyav (kg / m) | Ntev (m) | |||
| Lub taub hau | Qhov siab | Lub hauv qab | Qhov tuab | |||
| Gb6kg | 4 | 50.8 | 50.8 | 4.76 | 5.98 | 6-12 |
| Tus paagkg | 32.1 | 63.5 | 63.5 | 5.9 | 8.94 | |
| GB12kg | 38.1 | 69.85 | 69.85 | 7.54 | 12.2 | |
| Gb15kg | 42.86 | 79.37 | 79.37 | 8.33 | 15.2 | |
| GB22KG | 50.3 | 93.66 | 93.66 | 10.72 | 23.3 | |
| Gb30kg | 60.3 | 107.95 | 107.95 | 12.3 | - | |
| Txheem: YB222-63 | ||||||
| 8Kg | 25 | 65 | 54 | 7 | 8.42 | 6-12 |
| 18Kg | 40 | 90 | 80 | 10 | 18.06 | |
| 24kg | 51 | 107 | 92 | 10.9 | 24.46 | |
Suav Txheem Hnyav Rail
| Txheem: GB2585-2007 | ||||||
| Qhov loj | Dimension (mm) | Qho hnyav (kg / m) | Ntev (m) | |||
| Lub taub hau | Qhov siab | Lub hauv qab | Qhov tuab | |||
| P38kg | 68 | 134 | 114 | 13 | 38.733 | 12.5-25 |
| P43KG | 70 | 140 | 114 | 14.5 | 44.653 | |
| P ncuavkg | 70 | 152 | 132 | 15.5 | 51.514 | |
| Pvekg | 73 | 170 | 150 | 16.5 | 61.64 | |
Suav Txheem Crane Rail
| Txheem: YB / T5055-93 | ||||||
| Qhov loj | Dimension (mm) | Qho hnyav (kg / m) | Ntev (m) | |||
| Lub taub hau | Qhov siab | Lub hauv qab | Qhov tuab | |||
| Qu 70 | 70 | 120 | 120 | 28 | 52.8 | 12 |
| QU 80 | 80 | 130 | 130 | 32 | 63.69 | |
| Qu 100 | 100 | 150 | 150 | 38 | 88.96 | |
| QU 120 | 120 | 170 | 170 | 44 | 118.1 | |
Raws li cov kws ua haujlwm nrawm nrawm thauj khoom, Jindalai Steel tuaj yeem muab cov hlau txheem sib txawv hlau xws li Asmeskas, JIS, AIDLAM Africa uas siv hauv cov tsheb ciav hlau, cranes thiab thee mining.
